Automatic PU sandwich panel roll forming machine

    Payment Type: T/T,L/C
    Min. Order: 1 Set/Sets
    Delivery Time: 90 Days
Additional Info

Packaging: according to the machine design

Productivity: 500m/h

Brand: maxmach

Transportation: Ocean,Land

Place of Origin: zhejiang

Supply Ability: 500

Certificate: iso9001,ce,sgs,gmc

Product Description
General Description of the Automatic PU Sandwich Panel Roll Forming Machine
The technical plan made below is include the following part: hydraulic powered uncoiler, film covering equipment, Roll Forming Machine, the conveyor between uncoiler and roll forming machine, preheating oven, polyurethane foaming system, double belt conveyor, non-stop bandsaw, and the stacker.
Automatic PU sandwich panel roll forming machine Main Technical Parameters
Laminator Panel Spec.
Min. cutting length 3 meters
Panel width 900-1020mm
Panel thickness Mini thickness: the value is different according to different profile
Max. thickness: 150mm (without corrugated sandwich panel)
Steel Sheet Spec
Thickness 0.5-0.6mm
Width 1250mm
Max. coil weight 5tons
Inner Dia. of coil 508mm and 620mm
Automatic PU sandwich panel roll forming machine Spec
Working speed max. 6m/min (adjustable)
Total length about 115m
Working height 1200mm (height of panel coming out)
Pressure for foaming 150-200 bar
Control mode PLC
Power required 380V/3phase/50Hz
Control voltage 24V 110V 220v
Air pressure 0.7Mpa (for buyer to prepare)
Automatic PU sandwich panel roll forming machine Working flow
Active uncoiler film covering equipment (optional) Roll forming
Conveyor Preheating Foaming

Solidify ( double belt conveyor) Cutting Run out conveyor Automatic stack

Finished products show

Automatic PU sandwich panel roll forming machine1

Packing and shipping about the Automatic PU sandwich panel roll forming machine

packing and shipping


Looking for ideal Automatic Sandwich Making Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Pu Sandwich Panel Machine are quality guaranteed. We are China Origin Factory of Sandwich Panel Roll Forming Machine. If you have any question, please feel free to contact us.
